Product Details:
Payment & Shipping Terms:
|
| Specification parameter | ||
| system | Main Processor | GK7102 |
| image sensor | GC1034/GC2053 | |
| Operation System | Embedded LINUX OS system | |
| Video | High Definition | 720P/1080P |
| Video Compression | Smart H.264+ | |
| Rotation angle | Horizontal:355° ; vertical: 90° | |
| Object tracking | Support | |
| low illumination | 0.1LUX/F1.2 | |
| picture Capture | Support | |
| Video Flip | Support | |
| Audio | Coding standard | G.711 |
| Two-way Speech | Support | |
| Record management | Video file size | 2.5GB-4.5GB/Day |
| Record Mode | Manual record, motion detection record, scheduled record, alarm record | |
| Video storage | TF Card/Cloud | |
| playback, back up | Support | |
| Alarm trigger | Video Push,Alarm recording,screen shot capture ,sending Email | |
| Network | Network Interface | 1*RJ45 , 10/100M10-100 Base-T, self-adaptable Ethernet port |
| WIFI | 802.11b/g/n | |
| Bitstream | Three Stream | |
| Network Protocol | Support TCP/IP,RTSP,ONVIF, etc | |
| transmission mode | P2P,Smart Cloud Sever | |
| WIFI connection | Sweep QR code,Network Cable connection,AP Hotspot Addition | |
| extend | TF Card | Maximum support 128GB TF card |
| Reset key | Support | |
| power supply | Power | DC 5V 1.5A |
| Power consumption | 5W | |
| work environment | Suitable place | Home,shop,School,factory； |
| Installation mode | Flat put,Wall mounted,hoisting | |
| Working Temperature | -10℃－＋55℃ | |
| Working humidity | 10%－90% | |
| Other | Camera lens | 3.6MM |
| Lamp board | 6 pcs | |
| Product size | 113*113*100 (mm) | |
